Robots and drones take centre stage in £4.5m orchard project

A new project to develop a commercially viable system for precisely targeting orchard inputs to specific trees and tree parts has been given the green light.

Led by Hutchinsons agronomist Rob Saunders, and part-funded by the commercial partners, Innovate UK and Defra, the four-year, £4.5m Precision Orchard Management for the Environment (POME) project is using cutting-edge technology to digitally examine fruit trees in fine detail, allowing inputs to be targeted in a way that has never been seen before in UK orchards.

“The ultimate aim is to reduce the environmental impact of tree-fruit production by using fewer plant protection products, while simultaneously increasing orchard production efficiency, output and profitability through increased yield and grade-out,” Saunders explained.

The system will use digital scanning to generate precision-dosing maps for blossom and fruit thinning, fertiliser application, growth regulators, pest control, and fungicides, as well as provide more accurate yield forecasting for growers.

The integration with precision-dosing application equipment will together help to reduce the use of plant protection products, increase yields and cut fruit losses, he said. “It’s about raising the efficiency of how we use all resources that go into fruit production, including the land.”

Next-level precision

POME builds on work undertaken in a separate Innovate UK-funded Precision Orchard Dosing System (PODS) project that used LIDAR scanning of trees in winter to map height and density, before a drone-based scan in the spring to assess blossoms.

These data were analysed using machine vision and machine learning to develop a variable rate plan for applying thinners and growth regulators through a purpose-built sprayer fitted with RTK-GPS and robotic localisation and mapping techniques, giving high levels of accuracy in complicated horticulture environments.

“The aim of PODS was to prove the concept could work and develop a prototype,” explained Saunders. “Now, with the new POME project, we want to take all of that work on to the next stage and develop a commercially viable precision orchard management system that is ready for market in the next four years.”

Industry-wide consortium

Alongside Hutchinsons, project partners include engineers N. P. Seymour; Global Navigation Satellite System and software developer The Acclaimed Software Company; marketing desk Avalon Fresh; aerial imaging company Outfield; robotics firm Antobot; disease, pest and stress detection specialists Fotenix; horticultural experts from NIAB East Malling; data science expertise from NIAB Cambridge; agri-economics from the University of Kent; robotics and automation expertise from Loughborough University; and the Health and Safety Executive’s Chemicals Regulation Division (CRD).

How POME will work

There are three main elements to the POME project. The starting point is to gather data about the health and growth of orchard trees autonomously, rather than relying on the agronomist or grower having to walk up and down rows looking for differences or potential issues.

The team is developing three main ways of collecting data, including:

- Tractor-mounted sensors (e.g. hyperspectral imagery, NDVI, LIDAR scanning) to identify any variations in tree health or development. Having sensors mounted on the tractor allows a range of data to be collected every time the tractor passes through the orchard doing other operations

- Drone surveying during the flowering period to map blossom intensity of individual trees across the entire orchard

- Robot scanning from the ground. Scanning during daytime can be affected by variations in natural light intensity, therefore robot scanning will be done autonomously at night using artificial lights fitted to the vehicle, and carried out at low speeds that would not be practical for a tractor-based operation.

These three sources of data will then be brought together into a central computer software platform where everything can be analysed and interpreted to ultimately generate a user-friendly digital map of the orchard highlighting variations in any of the factors that the sensors recorded. This could include areas of a specific disease, or, as in the PODS project, variability in the size, density and crop load of individual trees - a major cause of sub-optimal yield and quality in commercial fruit orchards.

The final part of the project will develop a commercially viable application system that can use the data and digital maps generated to vary inputs according to the specific requirements of individual trees.
